In the high-stakes environment of industrial fluid handling, the ability to direct product flow without cross-contamination is paramount. UPASE PROCESS EQUIPMENTS specializes in the design and fabrication of premium Stainless Steel (SS) Flow Plates and Valve Manifold Panels, providing the modular flexibility and sterile security required by modern processing plants.
Our manifold systems act as the "central nervous system" of your liquid processing line, ensuring that every drop of product reaches its destination with zero leakage and maximum efficiency.
1. SS Flow Plates (Transfer Panels)
The SS Flow Plate, often called a Selection Panel or Transfer Panel, is a manual but highly secure method of routing fluids between different tanks or processing stations.
Key Engineering Features:
Proximity Sensor Integration: Our flow plates can be equipped with sensors that communicate with your PLC. This ensures that the pump will not start unless the "U-Bend" is correctly connected to the target port.
Leak-Proof Design: Precision-machined ports and heavy-duty gaskets prevent any atmospheric exposure.
Material of Construction: Fabricated from SS316L with high-grade internal polishing (Ra < 0.4 µm) to meet stringent FDA and GMP standards.
2. Advanced Valve Manifold Panels
For plants requiring high levels of automation and frequent CIP (Cleaning-In-Place) cycles, UPASE PROCESS EQUIPMENTS provides fully integrated Valve Manifold Panels. These systems replace manual swinging bends with automated mix-proof or butterfly valves.
Why Choose Our Manifold Panels?
Zero Cross-Contamination: Utilizing double-seat mix-proof valves, our manifolds allow the simultaneous flow of product and cleaning agents through adjacent pipes without any risk of mixing.
Compact Skid Design: We engineer our panels to be compact, saving valuable floor space while maintaining easy access for maintenance.
Complete Drainability: Every manifold is designed with a specific slope to ensure 100% self-draining, preventing stagnant product pockets.
Control Integration: Panels come pre-wired with solenoid valves and position feedback units, ready for immediate integration into your SCADA system.
3. Technical Specifications & Material Chart
| Feature | Specification |
| Material (MOC) | SS304, SS316, or SS316L |
| Surface Finish | Electro-polished (Mirror Finish) or Matte |
| Seal Materials | EPDM, Silicone, or Viton (FDA Approved) |
| Port Sizes | 1" to 6" depending on flow requirements |
| Pressure Rating | Up to 10 Bar (Customizable for high-pressure) |
| Mounting | Wall-mounted or Free-standing SS Skid |
4. Industrial Applications
UPASE PROCESS EQUIPMENTS caters to sectors where hygiene and routing precision are non-negotiable:
Dairy Industry: Directing raw milk, pasteurized milk, and cream to different storage silos simultaneously.
Pharmaceuticals: Routing purified water (WFI) and active ingredients in sterile formulation suites.
Brewery & Beverage: Managing the complex flow between fermentation tanks and filtration units.
Chemical Processing: Safe handling of corrosive fluids via high-alloy manifold systems.
5. The UPASE Engineering Advantage
When you choose a flow plate or manifold panel from UPASE PROCESS EQUIPMENTS, you are investing in:
Custom Design: We don't believe in "standard" manifolds. Every panel is 3D-modeled to fit your specific pipe-routing challenges.
Orbital Welding: All joints are orbitally welded to ensure smooth, crevice-free internal surfaces that inhibit bacterial growth.
Ease of Maintenance: Our "Swing-Out" valve designs allow for seal replacements without disrupting the entire piping network.
